Intelligent solar street lights manufacturer

• PV Panel: 25 years of power generation capacity and 20 years of warranty.
• LED Chips: Minimum 50.000 hours of life span, with a 3-year all-inclusive warranty that covers everything on the solar street lights, outdoor solar flood lights, solar garden lights, solar fans, and solar surveillance cameras.
• Lithium Battery: 5 to 7-year life span, with a 3-year warranty.
• Controller, inverter, and all the electronic parts: Minimum 8 years of ordinary usage, with a 3-year warranty.
• Solar street light pole, solar panel bracket, and all the metal parts: up to 10 years of life span.

• The sunshine time per day or the exact city in which the solar powered LED lights will be installed.
• How many continuous rainy days are there in the rainy season? (It matters because we have to make sure the light can still work in 3 or 4 rainy days.)
• The brightness of solar powered light bulbs you want (100 watts, for example)
• working time of pole solar street light every day (12 hours, example)
• The height of the solar street light poles, or the width of road.
• It is best to offer pictures of the locations where the led solar street light going to be installed.

YDSL uses PWM solar charge control, or MPPT solar controller, which uses a photocell or timer to control when the solar light on a pole will turn on, when the sun goes down, and when the sun comes up. The photocell detects when the sun comes down and when the sun comes up again. YDSL can make the solar powered street lamps install anywhere from 10 to 12 hours, and this varies depending on the customer’s needs. The solar controller utilizes an internal timer that is pre-set for a specific number of hours to determine when to switch the light off. If the solar controller is set to leave the light on until dawn, it determines when the sun rises (and when to switch the light off) by means of voltage readings from the solar panel array.

In order to customize your solar street lighting case, the first thing we need to focus on is the location for installing the street lights solar. Different locations have different sunlight, which can have an impact on the outcome of the solar panel street light project.

LiFePO4 batteries are becoming increasingly popular in solar street lights due to their long lifespan, lightweight, and high cycle life. Now lead-acid batteries have been completely replaced. Although lead-acid batteries work stably, their large size makes transportation inconvenient

Each of the street solar lights that YDSL makes is a combined light with a simple design. The solar street light installation can be put up by one person. It’s not a big deal.

Every single day, sunlight is preserved in the deep cycle lithium batteries, part of which is used to power the solar street lights at night. We typically build your system so that the battery can power the solar and battery lights for three nights without needing to be recharged. It means that even after a series of cloudy or rainy days, the lithium battery will have enough energy to power the light each evening. Although it is cloudy, the solar panel will continue to charge the battery.

Lithium Iron Phosphate (LiFePo4) vs Lithium Ion Batteries (18650)

• Lithium iron phosphate batteries have a 30% longer lifespan than lithium-ion batteries.
• The maximum decomposition temperature of lithium-ion battery cells is 700–800 degrees Celsius, preventing smoke and explosions.
• Lithium-ion batteries have better low-temperature resistance, while lithium iron phosphate is more resistant to high temperatures.

The specific type of battery to use depends on your solar street lights installation environment. You can also learn more from our professional articles: Solar light batteries: 18650 or 32650?

Compared to MPPT controllers, PWM (Pulse Width Modulation) is a simpler charging controller. The PWM controller uses very fast switches (multiple times per second) to control the current from the PV panel to battery charging. When the nominal voltage of the solar cell array matches the nominal voltage of the battery pack, the PWM controller works best.

The MPPT (Maximum Power Point Tracking) controller uses conversion technology for charging. The MPPT controller does not require the solar panel and battery pack to have the same nominal voltage. It can convert high-voltage PV power sources into low-voltage battery-pack charging power sources. The efficiency of MPPT controllers can be 30% higher than PWM, but for small solar lighting systems, they are usually more expensive and unnecessary.

Learn more about professional articles from MPPT controllers vs. PWM controllers.

The IP protection level is usually shown by two numbers after the IP.

First digit shows equipment dust resistance, The greatest level is 6.

The second digit represents equipment water prevention, at the highest level of 8.

Level of dust (initial X)

0. No protection

1. Prevent big solid penetration

2: Keep medium-sized solids out

3: Keep tiny solids out

4: Block solids over 1mm from entering

5: Avoid dusty conditions

6: No dust entry

The second X indicates waterproofness

0. No protection

1: Waterdrops entering the shell have no effect.

2. Water-drop do not impact the case when tilted 15 degrees.

3: Rainwater from a 60-degree angle does not affect the outer shell.

4: Any liquid splashing onto the shell does not hurt or impact it.

5: Wash safely.

6: For cabin environment.

7. Can resist 1m of water immersion.

8: Long-term water immersion under pressure
